14 min read

Elementor Navigation Menu: Every Setting Explained

Open the Elementor Nav Menu widget for the first time and it looks friendly: a menu picker, a layout switch, a few colors. Then you scroll the panel and find pointer styles, submenu indicators, a mobile breakpoint, a toggle button with its own hover state, and a full set of dropdown controls. Most people touch a handful of these and leave the rest at their defaults, then wonder why the menu feels slightly off on a phone or why the dropdown looks nothing like the bar above it.

This guide walks through the widget tab by tab, in the order you will actually meet the controls. It explains what each group does, which defaults tend to surprise people, and, just as useful, where the widget stops. The Nav Menu widget draws a menu. It does not make a header sticky, shrink it, or hide it on scroll, and knowing that boundary saves a lot of hunting through panels for a setting that does not exist.

Key Takeaways

  • The Nav Menu widget is part of Elementor Pro. It does not build menu structure itself; it displays a menu you already created under Appearance, then Menus.
  • Layout, pointer style, and the mobile breakpoint are separate controls. Changing one rarely fixes a problem that belongs to another.
  • Style options are split between the main menu bar, the dropdown panel, and the mobile toggle button, so each part can look different on purpose.
  • The widget has no sticky option and no scroll effects. Those belong to the header container or to a plugin built for the job.
  • Sticky Header Effects for Elementor adds sticky behavior and scroll effects on top of a Nav Menu header, and it works with Elementor Free or Pro.
  • Labels move around between Elementor releases, so treat the names below as a map, and trust what your own panel shows.

What the Nav Menu Widget Actually Is

The Nav Menu widget sits in the Theme Builder family of widgets that Elementor Pro ships. Its job is narrow and useful: take a WordPress menu, render it as clean markup, and give you visual controls for the bar, the submenus, and the mobile toggle. It is a common choice inside a header template because it already understands things like the current page, parent items, and submenu arrows. In some newer Elementor releases the same widget appears under the name WordPress Menu, so search for either label.

If you are still deciding how the pieces of a header fit together, our complete guide to Elementor headers covers the template, the sections inside it, and where each widget belongs. Here we stay inside the widget itself.

Diagram showing where the menu source, the Nav Menu widget settings, and sticky header behavior are each controlled in Elementor
Three layers make up a Nav Menu header: the WordPress menu, the widget that displays it, and the header behavior around it.

Because it is a Pro widget, a site on Elementor Free will not see it in the panel. Free users build a menu with the WordPress menu screen and a theme location, or use a different widget, and the same planning advice below still applies to the menu structure.

Where the Widget Gets Its Menu

The first control in the Content tab is the Menu dropdown. It lists every menu you have saved under Appearance, then Menus in wp-admin. Elementor does not let you add, reorder, or nest items inside the widget. All of that happens in the WordPress menu editor, and the widget simply reads the result.

That single dependency explains a surprising number of support questions. If the dropdown is empty, no menu exists yet. If the menu renders but looks wrong, the cause is often the menu itself: an item with the wrong parent, a custom link missing its URL, or a page that was trashed after being added. Fix the menu first. If you have never built one, our walkthrough on adding a menu in WordPress walks through the steps.

Rename items and set their order in the menu editor, not by overriding text in Elementor. A menu that is correct at the source stays correct if you later swap the widget for a different one or reuse the same menu in a footer.

Layout Controls in the Content Tab

Layout is the control that changes the whole shape of the menu. Horizontal lays every top-level item in a row, Vertical stacks them in a column, and Dropdown collapses everything behind a single toggle. A common pattern is Horizontal for desktop headers, with the mobile setting taking over on small screens, but Dropdown is also a legitimate choice on desktop when you want a minimal header.

Alignment decides where the items sit inside the widget: left, center, right, or justified. If the menu looks off-center, check this before reaching for margins, and then check the alignment of the column or container that holds the widget, because both affect the result.

Pointer controls the hover effect on top-level items. Options include none, underline, double line, framed, background, and text, and most of them come with an animation choice that decides how the effect moves in. Pointer is purely visual, so it is a safe place to experiment. Pick a style that matches how loud the rest of your header is. A framed pointer on a quiet, minimal header tends to look heavy, while a plain underline works almost everywhere.

Elementor Nav Menu widget layout settings in the Content tab
Layout switches between horizontal and dropdown display. A vertical arrangement is chosen with the Vertical layout option rather than a separate menu type.

Submenu Indicator adds or removes the small arrow beside items that have children. It is easy to forget, and it matters more than it looks: on touch screens the arrow is the only hint that an item opens something instead of going to a page.

Mobile Dropdown Settings

The widget has its own idea of when to switch to a mobile menu, and it is set in the Content tab under the dropdown options. Instead of a pixel value, you choose a device range at which the horizontal menu collapses into a toggle button. Below that range, visitors see the toggle and tap it to open the list of items.

Three things in this area are independent of each other, and mixing them up causes most mobile surprises. The breakpoint decides when the collapse happens. The toggle button controls which icon appears and where it sits. The full width option decides whether the opened list spans the full width of the screen.

Test on a real phone, or at least a true device preview, not just a narrowed desktop window. Touch behavior differs from mouse behavior, especially for submenus that open on hover on desktop. Our guides on building a hamburger menu and on sticky headers on mobile go deeper on what to look for.

Elementor Nav Menu widget hamburger toggle icon settings for mobile
The toggle icon, the breakpoint, and the full width behavior are separate settings, not one combined control.

Style Tab: Main Menu

The Style tab is split by part of the menu. The main menu section handles top-level items: typography, text color in normal, hover, and active states, the pointer color and width, and the spacing around and between items. Pointer color applies to the hover and active states, and giving the current page’s item a clear visual cue is one of the cheapest ways to make a menu feel finished.

Spacing is where menus usually go wrong. Padding inside each item controls how large the clickable area is, while the space between items controls how the row breathes. Generous padding helps on touch screens, because a tight row of small links is hard to tap accurately. Set the padding for the size you want to tap, then adjust the gap to keep the row balanced.

Typography here applies to top-level items only. If you want submenu text to match, you will set it again in the dropdown section. That is by design, since a dropdown often looks better with slightly smaller text than the bar above it.

Style Tab: Dropdown and Submenus

Any menu item that has children in your WordPress menu becomes a submenu trigger. The Dropdown section of the Style tab then controls the panel that opens: its background and text colors, typography, border, corner radius, shadow, padding, and dividers. You can make the panel look like a different component altogether, and many sites do, with a light panel under a dark header or a soft shadow to lift it off the page.

One level of submenus works cleanly in this widget. In our experience a second level still works, but it is harder to use on a touch screen, because a visitor has to open two flyouts in a row. Anything more elaborate, such as multiple columns, images, or featured links inside a dropdown, is mega menu territory, and that needs a different tool. We compare the options in our mega menu setup guide and explain what is possible without extra plugins in building a mega menu without a third-party plugin.

If your dropdown opens behind the content below it, that is a stacking problem rather than a styling one. We cover the usual causes in fixing a dropdown that hides behind content.

Elementor submenu dropdown opening on hover from the Nav Menu widget
Hover is the common trigger for a submenu on desktop. Test the touch version separately, because hover has no real equivalent on a phone.

Style Tab: The Toggle Button

The toggle button has its own style group. You can set its size, icon color, and background for normal and hover states, plus a border and radius. People skip this group and end up with a hamburger icon that is too small or too faint on a colored header. Make the toggle as easy to see as your logo, since on a phone it is the main way into the whole site.

If the opened list looks cramped, adjust the dropdown typography and padding as well. In our testing, the opened mobile list follows the dropdown styling rather than the main bar styling, which can surprise people who spent an hour perfecting the desktop look. Check it in the device preview.

Responsive Controls and Per-Device Tweaks

Most controls in the widget have a small device icon beside them. Click it and you can set a different value for tablet or mobile. This is how you keep large type and wide spacing on desktop while tightening both on a phone. Set the desktop version first, then check each smaller view and override only what needs to change, so the settings stay easy to reason about later.

Tablet deserves its own look. A width that is too wide for the mobile toggle and too narrow for a full horizontal row is where menus most often break, with items wrapping onto a second line or crowding the logo. Preview the in-between sizes, not just the two extremes, and decide deliberately whether tablet should show the full menu or the toggle.

Planning Menu Structure Before You Style Anything

A messy menu is more often a planning problem than a styling problem. Decide which top-level items really need children before you add a single submenu, because every dropdown adds one more hover or tap a visitor must complete. A short top-level list with at most one level of dropdowns is easier to scan and easier to use on every device.

Label choice matters as much as structure. Short, plain words such as Pricing, Docs, or Contact scan faster than clever phrases, and they stay on one line when the header gets tight. If a label needs more than two or three words, it probably belongs inside a dropdown or needs a clearer name.

If your content needs deeper hierarchy, treat that as a signal. It may call for a mega menu, or for better page-level navigation such as category pages and an on-page table of contents, instead of a deeper nest of flyouts. For a quick reference on how WordPress stores menus and renders them, the official navigation menus documentation is a reliable source.

What the Nav Menu Widget Does Not Do

The Nav Menu widget has no sticky control and no scroll behavior. There is nothing in its panel that makes the menu stay at the top, change color after scrolling, shrink, or disappear when a visitor scrolls down. Sticky positioning belongs to the container or template that holds the widget, which is why you will not find it by searching through the widget’s own tabs.

In Elementor Pro, the header container has basic sticky settings under Advanced, then Motion Effects, in the standard editor. For anything beyond a simple fixed position, a dedicated plugin is the practical route. Sticky Header Effects for Elementor works with Elementor Free or Pro and has 300,000+ active installs on WordPress.org. It adds sticky behavior and scroll effects such as shrinking, changing the background color, blurring, and hiding the header on scroll down, and it works on top of your existing Nav Menu header.

That separation is useful. You design the menu with the widget, then add behavior to the header around it. Start with our Elementor sticky header setup guide for the first steps, and see hiding the header on scroll down and shrinking the header on scroll for two common effects.

If you are weighing different ways to handle headers overall, our comparison of header and footer builder plugins lays out the trade-offs.

A Quick Checklist Before You Publish a Menu

  • Confirm the menu exists in Appearance, then Menus, and that every item points to a live page.
  • Pick Horizontal or Dropdown on purpose, and check alignment inside the column too.
  • Choose a pointer style that fits the rest of the header, and give the current page’s item a clear cue.
  • Set the mobile breakpoint, then open the toggle on a real phone and tap every item.
  • Style the dropdown panel and the toggle button separately from the main bar.
  • Add sticky behavior or scroll effects at the header level, not inside the widget.

Frequently Asked Questions

Why Is My Nav Menu Widget Showing Nothing?

The Menu control has no menu selected, or the selected menu has no items. Build and save the menu under Appearance, then Menus, return to the widget, and choose it from the dropdown.

Is the Nav Menu Widget Free?

No. It is part of Elementor Pro. On Elementor Free you build the menu in WordPress and display it through your theme or another widget.

Can I Build a Mega Menu With This Widget?

Not a true multi-column one. The widget supports single-column dropdown submenus. A mega menu with columns, images, or custom content needs a dedicated mega menu tool.

Does the Nav Menu Widget Support Sticky Behavior on Scroll?

No. Sticky positioning and scroll effects are handled at the header level, either through Elementor Pro container settings for basic cases or through a plugin such as Sticky Header Effects for Elementor.

Why Does My Mobile Menu Look Different From the Desktop Menu?

They use separate style groups. In our testing the opened mobile list follows the dropdown styling, and the toggle button has its own style group, so desktop changes to the main bar do not always carry over.

Where Should I Change Menu Item Names and Order?

In the WordPress menu editor. The widget only displays the menu, so edits made there appear everywhere the menu is used.

Suggested Reading

Browse the Sticky Header Effects documentation for the scroll behavior the Nav Menu widget does not cover.
